Double-click on the workaround where the tile and text can't be edited

time：2024-12-22 16:02:39 Review Insights

Why can't CAD double-click blocks and text be edited?

Normally, double-clicking a block in CAD will open a quick edit, double-clicking on a text will edit the text, etc. But why do you sometimes double-click on a graphic but don't start editing? There are several reasons for this:

One, the "select before execute" option is turned off

Second, the option of "double click to edit" is turned off. This option also controls whether you can double-click to edit, and can be checked if the select before you command appears correctly.

Third, we can set the commands we execute by double-clicking on the object graph, for example, double-clicking on a tile executes the BEDIT-block editing command by default, but we can also set it to execute other commands. So, if there is no problem with the first two methods, it is likely that the settings have been modified.
